Higo Electric Bicycle Male female Snap-in Plug Sensor Waterproof Cable Connector China Manufacturer Ebike conversion kit Signal Harness

Color:
Samples:
price:
Availability:
Quantity:
  • F.S-Z305

  • Super-ecs

  • SUP-F.S-Z305

Product Introduction

20220414_160441_00620220414_160441_005

20220414_160441_009

scope of application The electric bike, Scooter,motorcycle, industry;The LED industry and so on.
Types waterproof plug/waterproof connectors/waterproof connectors/Multi-split  waterproof plug/nylon waterproof plug/fabricated waterproof plug
Interface type AC/DC
Shape round
Feature waterproof
Contact material pure phosphor copper
Joint material PVC/PBT/PA66 / PC + ABS
Rated voltage 48V AC/DC
Rated current 2A
Withstand voltage 500V(special require should be mentioned in advance)
Working temperature -25℃~+80℃
Protection grade IP66
Insulation resistance ≥20MΩ
Contact resistance ≤10mΩ
Certification can according to customer's requirements with CCC, VDE, UL, ROHS, SGS, etc all kinds of wire
Appearance  color black(optional)
Cable length 31.7mm(any long  can be customized for customer request)
outer diameter 5.5mm
